Chapter 8: Installation 8-25
Radar System
Checks and
Adjustments
rent settings. The complete list, which you can scroll down, is shown in the
following illustration.
Figure 8-14: System Set Up Menu (SL72 PLUS)
3. Use the trackpad to move the selection bar down to the LANGUAGE option.
the soft key labels are updated.
4. Use the soft keys to highlight the required language.
5. Press
ENTER to return to the setup soft keys.
6. Press
CLEAR to return to the normal radar screen.
Radar System Checks and Adjustments
When the display is connected to a scanner unit you should perform the checks
and adjustments detailed below.
Transmission Check
WARNING:
The radar scanner transmits electromagnetic energy. Ensure that the
scanner has been installed according to the recommendations given in
this handbook and that all personnel are clear of the scanner, before
switching to transmit mode.
D3650-5
SYSTEM SET UP MENU
DATA BOXES
BEARING MODE
CURSOR REFERENCE
CURSOR READOUT
DAY/NIGHT
HELP
SOFT KEYS
KEY BEEP
MOB DATA
MENU TIMEOUT PERIOD
DISTANCE UNITS
SPEED UNITS
DEPTH UNITS
TEMPERATURE UNITS
VARIATION SOURCE
BRIDGE NMEA HEADING
DATA SELECTION
CURSOR ECHO
DATE FORMAT
TIME FORMAT
TIME OFFSET
LANGUAGE
SIMULATOR
TRUE
RELATIVE
RNG/BRG
RNG/BRG
ON
ON
ON
DR
NO TIMEOUT
NAUTICAL MILES
KNOTS
METRES
CENTIGRADE
AUTOMATIC
ON
SEATALK/NMEA IN
DD/MM/YY
24 HOUR
UTC
ENGLISH (US)
OFF
