Raymarine SL72 User Manual

Chapter 2: Getting Started & Adjusting the Display 2-13
Customizing the
Screen Presentation
Options
Customizing the Screen Presentation Options
The SCREEN soft key lets you set the following screen presentation options on
or off:
Radar:
Chart (SL72RC PLUS only):
Switching the Cursor Data Box On and Off
The cursor data box provides the cursor’s position in latitude/longitude and/or
bearing/range. If you wish to see a full image, you can switch the data box off.
➤ To control the cursor data box:
1. Press the
SCREEN soft key.
2. Press the
CRSR BOX soft key to toggle the setting from OFF to ON or from ON
to OFF.
3. To return to the default soft key display, press
ENTER.
➤ You can move the cursor data box using the context-sensitive cursor.
Switching Radar Range Rings or Chart Grid On and Off
The radar range rings can be turned on or off. They are normally left on, but
you may wish to turn them off if you are using VRM/EBLs or guard zones (see
Section 3.4 and Section 3.5) to make the display clearer.
The Chartplotter display includes grid lines of latitude and longitude which
you can use to help determine position on the chart. The grid lines can be
switched on if required.
If you are in Chart mode the
RNGE RNGS soft key is replaced by the CHRT GRID
soft key.
➤ To turn the range rings or chart grid on or off:
1. Press the
SCREEN default soft key.
2. Press the
RANGE RINGS or the CHRT GRID soft key to toggle the setting from
OFF to ON or from ON to OFF.
To return to the default soft key display, press
ENTER.
D3643-2
SCREEN
CRSR BOX
OFF ON
RNGE RNGS
OFF ON
DATABOXES
OFF ON
WAYPOINT
OFF ON
D4177-1
CRSR BOX
OFF ON
CHRT GRID
OFF ON
DATABOXES
OFF ON
CUSTOM
OFF ON
SCREEN
CRSR BOX
OFF ON
SCREEN
RNGE RNGS
OFF ON
