Re T-one ULS User Manual

T-one ULS
Rev. 06/18 15/26
Diameter reference
If F.30 = 1.
It accepts an analog reference proportional to the diameter. It can come from an ultrasound sensor (e.g.
US3), or from any sensor or controller that has a 4÷20mA signal.
Remote set point
If F.30 = 0.
It accepts an analog reference proportional to the maximum SETPOINT (100.0) desired for the material; a
potentiometer (manual setting) or the analog output of any control device can be connected to it (e.g. PLC).
Analog input AIN1
Pin 20 ( + ); Pin 19 ( - )
The signal must be 0÷10V, ΔV>1,1V.
Diameter reference
If F.30 = 0.
It accepts an analog reference proportional to the diameter. It can come from an ultrasound sensor (e.g.
US3), from the potentiometer of a feeler or from any sensor or controller that has a 0÷10Vdc signal.
Remote set point
If F.30 = 1.
It accepts an analog reference proportional to the maximum SETPOINT (100.0) desired for the material; a
potentiometer (manual setting) or the analog output of any control device can be connected to it (e.g. PLC).
If you use a potentiometer (manual setting) the potentiometer supply tension is provided by Pin 8 (9V).
Analog output proportional to the diameter
Pin 22 ( + ); Pin 21 ( - )
The output signal is 0÷10V.
Proportional to the diameter
It provides an analog reference which can be used to display on a remote display the reel diameter detected.
Analog output adjustment
Pin 24 ( + ); Pin 23 ( - )
Type of output signal:
 if F.70 = 0 0÷10V
 if F.70 = 1 4÷20mA
Brake or clutch control
It provides a command analog reference (torque adjustment) for a brake/clutch; the analog input of the
electro-pneumatic transducer (pneumatic brake) or, using the Re S.p.A. FP25 or TAURUS command board, a
magnetic powder brake, must be connected to it.
