Re T-one ULS User Manual

T-one ULS
Rev. 06/18 20/26
 Press up or down and set 0 if you desire to control the set point through the keypad or 1 to manage it
from analog input.
 Press enter to confirm.
 If the remote set point is enabled, position on function 37 and then on function 38 in order to calibrate
the analog reference.
Function 37 – Setting the minimum value of remote set point
The function is active if F.36 = 1.
 Adjust the analog input (AIN1 if F.30 = 0, AIN0 if F.30 = 1) in order to supply the minimum analog
signal to the instrument (e.g.: 0V if acquired from AIN1, 4mA if acquired from AIN0).
 Press enter, the word “YES” flashes on the display for a few seconds; then function 37 is displayed
again;
Function 38 – Setting the maximum value of remote set point
The function is active if F.36 = 1.
 Adjust the analog input (AIN1 if F.30 = 0, AIN0 if F.30 = 1) in order to supply the maximum analog
signal to the instrument (e.g.: 10V if acquired from AIN1, 20mA if acquired from AIN0).
 Press enter and the word “YES” or “BAD” flashes on the display for a few seconds, respectively if the
calibration was successful or not; then function 38 is displayed again.
Note: if “BAD” is shown on the display check that the analog reference connection has been performed
correctly and that the range of the analog signal between minimum and maximum is at least 1/3 of the
acquisition range of the selected input (at least 5mA if acquired from AINO, at least 3Vdc if acquired from
AIN1)
Function 39 – Remote control
Use this function to set the AUTO/STOP control
 Press enter to access the function and the function value set is displayed.
 Press up or down and set 0 to manage the AUTO/STOP control by keypad, or 1 to manage it through
the remote contact.
 Press enter to confirm.
Function 50 – Braking section 1 percentage (SECT.1)
Use this function to set the percentage of the caliper or calipers that make up the braking section 1 (SECT.1),
intended as the total of the percentages of the calipers that make up the SECT.1.
This braking section is always active (see § “Selematic” function on page 4)
 Press enter to access the function and the function value set is displayed.
 Press up or down and set the desired percentage.
 Press enter to confirm.
Example: if SECT.1 is composed by a RED caliper (40%) and a BLUE caliper (16%) the percentage set in F.50
is 56% (40% + 16%).
Note: this section is always included, therefore when the Selematic function is not active the value of this
function must be 200.
Function 51 – Braking section 2 percentage (SECT.2)
Use this function to set the percentage of the caliper or calipers that make up the braking section 2 (SECT.2),
intended as the total of the percentages of the calipers that make up the SECT.2.
This braking section will be included/excluded with the electro valve (see § “Selematic” function on page 4)
