• Weighing reports export
• Connecting scale to printer
6.3 USB (B) port
USB port of type B is intended for connecting the scale to a computer in order to make connection of
scale to computer, it is necessary to install virtual COM port on the computer.
7. Peripheral devices
<P5.ducE> menu contains list of devices connecting with the scale.
7.1 Computer
<5.1.PC> submenu allows to:
• Select port to which the computer is connected
• Enable/disable continuous transmission
• Set frequency of printouts for continuous transmission
7.1.1 Port
1. Enter <P5.1.PC / 5.1.1.Prt> submenu.
2. Press key, port options are displayed successively, where: nonE – none, rS1 – RS232
(1), USbb – USB type B.
3. Set respective value and press key to confirm, next go to the home screen.
7.1.2 Continuous transmission
1. Enter <P5.1.PC / 5.1.2.Cnt> submenu.
2. Press key, transmission options are displayed successively, where: nonE – Continuous
transmission disabled, CntA – Continuous transmission in basic unit, Cntb – Continuous
transmission in current/temporary unit.
3. Set respective value and press key to confirm, next go to the home screen.
7.1.3 Printout interval for continuous transmission
Parameter to set frequency of printout for continuous transmission. Printout interval is set in
seconds, with 0.1 [s] accuracy within 0.1 [s] – 3600 [s] range.
1. Enter <P5.1.PC / 5.1.3.Int> submenu.
2. Enter transmission rate, to do this press to select digit to be edited and to set
digit value (0 - 9).
3. Set respective value and press key to confirm, next go to the home screen.
7.1.4 Printer
<5.2.Prtr> submenu allows to:
• Select port to which the printer is connected
To Next Page
