1. Place the balance on a solid surface to ensure stability. Operate the balance in a room where
the temperature ranges between 10 - 40
o
C (50 - 104
o
F).
2. The balance must be positioned away from heat sources, magnetic fields, vibrations, and air
drafts to receive stable and repeatable results. Balance is to not be used for explosive
materials.
2.1 System assembly
1. Check the grounding spring located in the rubber foot with spring. The spring must jut
slightly out of the hole.
Figure 3. Grounding spring check
2. Install the rubber foot with spring into any freely selected opening. Install 3 x solid rubber
feet in remaining openings.
Figure 4. Rubber feet installation
3. Install the weighing pan.
