Available Options
33
3
Option Installation Flow Chart
We recommend you install multiple options in the following order:
A Attach the paper feed unit ( Paper Feed Unit Type 4000 ).
Attach the paper feed unit to the bottom of the printer.
You can attach up to two paper feed unit. Up to 1750 sheets of paper can be
loaded.
B Install the SDRAM module ( Memory Unit Type D 128MB, Memory Unit
Type E 256MB ).
Install the module to the SDRAM module slot on the controller board.
There are two types of memory unit: 128 MB and 256 MB.
C Install the user account enhance unit ( User Account Enhance Unit Type E ).
Install the module to the user account enhance unit slot of the controller
board.
D Install the hard disk drive ( Hard Disk Drive Type 4000 ).
Install the hard disk drive to the controller board.
E Install the IEEE 1394 interface board, IEEE 1284 interface board, IEEE
802.11b interface unit or Bluetooth interface unit.
Install the IEEE 1394 interface board, IEEE 1284 interface board, IEEE 802.11b
interface unit or Bluetooth interface unit on the controller board.
The IEEE 1394 interface board and standard Ethernet interface cannot be used
at the same time.
Up to two of the following can be installed:
• IEEE 1394 Interface Board Type B
• IEEE 1284 Interface Board Type A
• IEEE 802.11b Interface Unit Type H
• Bluetooth Interface Unit Type 3245
F Install the network data protection unit ( Network Data Protection Unit
Type B ).
Insert the network data protection unit into the SD card slot on the controller
board.
GaiaP1GB_Setup-F4_FM_forPaper.book Page 33 Friday, June 3, 2005 7:50 AM
To Next Page
