User’s Guide for DS1000B Series
5-6
General Specifications
Display
Display Type 5.7 inch. (145 mm) diagonal TFT Liquid Crystal
Display
Display Resolution 320 horizontal ×RGB×240 vertical pixels
Display Color 64k color
Display Contrast (typical) 150:1
Backlight Brightness (typical) 300 nit
Probe Compensator Output
Output Voltage (typical) Approximately 3Vpp (peak to peak value)
Frequency (typical) 1kHz
Power
Supply Voltage AC, 100~240 V, 45~440Hz, CAT II
Power Consumption Less than 50W
Fuse 2A, T rating, 250 V
Environmental
Ambient Temperature
Operating 10℃~ 40℃
Non-operating -20℃~ +60℃
Cooling Method Fan force air flow
Humidity
+35℃ or below: ≤90% relative humidity
+35℃~ +40℃: ≤60% relative humidity
Altitude Operating 3,000 m or below
Non-operating 15,000 m or below
Mechanical
Size Width 325mm
Height 159mm
Depth 133 mm
Heavy Without package 3kg
Packaged 4.3 kg
IP Protection
IP2X
Calibration Interval
The recommended calibration interval is one year
