Rockwell Automation Allen-Bradley 1769-IA16 User Manual

20 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 1 Install a 1769 Module
Wire Size and Terminal Screw Torque
Each terminal accepts one or two wires with the following restrictions.
Wire Type Wire Size Terminal Screw
Torque
Retaining Screw
Torque
Solid Cu-90 °C (194 °F) #14…#22 AWG 0.68 N•m (6 lb•in) 0.46 N•m (4.1 lb•in)
Stranded Cu-90 °C (194 °F) #16…#22 AWG 0.68 N•m (6 lb•in) 0.46 N•m (4.1 lb•in)
