Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 27
Module Wiring Chapter 2
1769-IF8
Compact voltage/current analog input module
+
–
V in 4+
V/I in 4-
I in 4+
ANLG Com
V in 5+
V/I in 5-
I in 5+
ANLG Com
V in 6+
V/I in 6-
I in 6+
ANLG Com
V in 7+
V/I in 7-
I in 7+
ANLG Com
NC
NC
+
–
V in 0+
V/I in 0-
I in 0+
ANLG Com
V in 1+
V/I in 1-
I in 1+
ANLG Com
V in 2+
V/I in 2-
I in 2+
ANLG Com
V in 3+
V/I in 3-
I in 3+
ANLG Com
NC
NC
1769-IF8 Differen tial Inputs
+
V in 0 +
V/I
in 0 -
I in 0 +
AN LG C o m
V in 1 +
V/I
in 1 -
I in 1 +
AN LG C o m
V in 2 +
V/I
in 2 -
I in 2 +
AN LG C o m
V in 3 +
V/I
in 3 -
I in 3 +
AN LG C o m
NC
NC
+
+
+
-
1769-IF8 Single-ended Sensor/Transmitter Inputs
The sensor power supply must be rated Class 2.
Analog SourceBelden 8761 Cable (or equivalent)
Earth ground the shield
locally at the module.
Sensor/
Transmitter
Supply
Current
Voltage
Voltage
Signal
Signal
Ground
Signal
Ground
Wiring for channels 4…7 are identical.
