Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 93
I/O Memory Mapping Chapter 3
Configuration File
The read/writable configuration data file allows the setup of the digital filter
settings for each of the two input groups. Group 0 is inputs 0…7 and Group 1 is
inputs 8…15.
The manipulation of the bits from this file is normally done with programming
software, such as RSLogix 500, RSLogix 5000, or RSNetWorx for DeviceNet
software, during initial configuration of the system. In that case, graphical screens
are provided via the programmer to simplify configuration. However, some
systems, like the1769-ADN DeviceNet adapter, also allow the bits to be altered as
part of the control program using communication rungs. In that case, it is
necessary to understand the bit arrangement.
Word
Bit Position
1514131211109876543210
0 Filter Time On to Off
Group 1
Filter Time Off to On
Group 1
Filter Time On to Off
Group 0
Filter Time Off to On
Group 0
1 0000000000000000
2 0000000000000000
3 0000000000000000
Filter Time
(1)
(1) Filter Time: Word 0, the Filter Time configures the ON to OFF
and OFF to ON hardware delay times for each input group.
Bit Setting
8.0 ms 0000
4.0 ms 0001
2.0 ms 0010
1.0 ms 0011
0.5 ms 0100
0.1 ms 0101
0.0 ms 0110
