80 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
1769-IF16C
The following I/O memory mapping lets you configure the 1769-IF16C module.
Input Data File
For each module, slot x, words 0…15 in the input data file contain the converted
value of the module’s analog input channels. Word 16 in the input data file
contains the time stamp value, if time stamping is enabled, that corresponds to
the module's last input data sampling period. Words 17…21 in the input data file
contain status bits for the analog input channels.
Word
Bit Position
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
0 SGN Analog Read (Input) Data Value Channel 0
1 SGN Analog Read (Input) Data Value Channel 1
2 SGN Analog Read (Input) Data Value Channel 2
3 SGN Analog Read (Input) Data Value Channel 3
4 SGN Analog Read (Input) Data Value Channel 4
5 SGN Analog Read (Input) Data Value Channel 5
6 SGN Analog Read (Input) Data Value Channel 6
7 SGN Analog Read (Input) Data Value Channel 7
8 SGN Analog Read (Input) Data Value Channel 8
9 SGN Analog Read (Input) Data Value Channel 9
10 SGN Analog Read (Input) Data Value Channel 10
11 SGN Analog Read (Input) Data Value Channel 11
12 SGN Analog Read (Input) Data Value Channel 12
13 SGN Analog Read (Input) Data Value Channel 13
14 SGN Analog Read (Input) Data Value Channel 14
15 SGN Analog Read (Input) Data Value Channel 15
16 Nu Time Stamp Value
17 S15 S14 S13 S12 S11 S10 S9 S8 S7 S6 S5 S4 S3 S2 S1 S0
18 L3 H3 U3 O3 L2 H2 U2 O2 L1 H1 U1 O1 L0 H0 U0 O0
19 L7 H7 U7 O7 L6 H6 U6 O6 L5 H5 U5 O5 L4 H4 U4 O4
20 L11 H11 U11 O11 L10 H10 U10 O10 L9 H9 U9 O9 L8 H8 U8 O8
21 L15 H15 U15 O15 L14 H14 U14 O14 L13 H13 U13 O13 L12 H12 U12 O12
