Key Operation from Top Menu:
Press the key.
Tool up / down
Default
Menu
• Move the tool up or down
Replot Clear
Toll[UP]
Operation Procedure : The key toggles between [UP] and [DOWN] settings.
• When cutting operations are not being performed, the tool carriage rests in the up position.
Key Operation from Top Menu:
Press the key two times and continue by pressing the and keys.
VS Command
Menu
Operation Procedure : The key toggles between [ON] and [OFF] settings.
Default
• ON Set to the speed designated by the computer. (It is not possible to make settings that exceed the
device's maximum speed of 72 cm/sec.)
• OFF Cutting is performed at the speed set on the cutting machine.
OFF
• Performing a cut using speed settings made on the computer.
VSCommand[OFF]
Toolstop[ ON]
Key Operation from Top Menu:
Press the key two times.
Default
Menu
Operation Procedure : Refer to section " 8. Seting Cutting Conditions " .
10 cm/sec.
• Set the speed
CutTest [10cm/s]
DOWN 10cm/s UP
Speed
Key Operation from Top Menu:
Press the key twice, then press the key, and press the key twice again.
Default
Menu
ON
• Cutting Attractive Arcs
Smoothing
Operation Procedure : The key toggles between [ON] and [OFF] settings.
• ON Arcs and other curves are cut attractively. The machine is shipped with this set to "ON."
• OFF Set this to OFF if excessive smoothing results in angular corners being rounded when cut.
Smoothing [ON]
