32
Interface Specifications
3. Specifications
PNC-1610
Feature Flatbed
Max. cutting area
923 mm x 618 mm
36-5/16" x 24-5/16"
Max. cutting speed 720 mm (28-5/16") / sec.
Max. tool force 500 gf
Acceptable material thickness 16 mm (5/8")
Acceptable material widths 650 mm (25-9/16")
Number of tool up/down 4 per sec. (Moves the tool up and down one time)
Mechanical resolution 0.005 mm / step
Software resolution 0.025 mm / step
Distance accuracy ±0.1 mm or ±0.1% of the distance traveled, whichever is larger (same pen/ with drafting film)
Repetition accuracy ± 0.1 mm or less (same pen/ with drafting film)
Interface Paralell ( in compliance with the specification of Centronics ) , Serial ( RS-232C specification )
Buffer size 1 M byte
Instruction system CAMM-GL III (mode1, mode2)
Control switch
LED [PAUSE], [VIEW]
Display Liquid crystal display (16 characters x 2 lines)
Acoustic noise level under 55 dB(A) (According to ISO 7779)
Power consumption
0.5 A / 117 V
0.3 A / 220 — 230 V
0.3 A / 240 V
External dimensions 1214 ( W ) x 841 ( D ) x 187( H ) mm
47-13/16" ( W ) x 33-2/16"( D ) x 7-6/16" ( H )
Weight 27 kg (59.5 lb. )
Operating temperature 5 — 40°C (41—104°F)
Operating humidity 35% — 75% (non-condensing )
[Parallel]
Standard In Compliance with the specification of Centronics
Input Signal STROBE ( 1BIT ), DATA (8BITS )
Output Signal BUSY ( 1BIT ), ACK ( 1BIT )
I/O Signal Level TTL level
Transmission Method Asynchronous
[Serial]
Standard RS-232 Specifications
Transmission Method Asynchronous, duplex data transmission
Transmission Speed 1200, 2400, 4800, 9600, 19200
Parity Check Odd, Even, None
Data Bits 7 bits 8 bits
Stop Bits 1 bit or 2 bits
, , , , FAST, ENTER, NEXT, PAUSE, VIEW, F1, F2, F3, F4
