3-5 Starting Cutting
Material Test Feed
Perform test feed beforehand to ensure that the roll material is not pulled with undue force during cutting.
If the roll material is pulled with undue force during cutting, a motor error may occur, or the position may be displaced. Test feed can
also be performed to make sure that the loaded material is straight.
Using the [AREA] feature makes it simple to perform test feed for the required portion.
Make sure that the type of the material has been selected using the operation panel and that material loading has been completed.
1
Make sure the brake is released.
2
Press the [MENU] key several times until the screen
shown in the figure appears.
3
Press the [ ] key.
4
Press the [ ] key.
Press the [
] key several times.
Press the [ ] key.
Use the [
] and [ ] keys to make the setting for the
required material length. Set the length that is about
0.2 m longer than the required material length.
(A positive value signifies material feed toward the
front, and a negative value signifies material feed
toward the back. If you are performing front loading,
set the length to a negative value. For more informa-
tion, see “4-6 Front Loading.” )
6
Press the [ENTER] key to perform test feed.
Press the [MENU] key to go back to the screen shown
in the figure.
AREA 1.0m
AREA 1.0m
*2.0m
20cm/s
50gf 0.250mm A
5
To Next Page
