Standard Universal Serial Bus Specification Revision 1.1
Universal Serial Bus Device Class Definition for Printing Device Version 1.1
Transmission speed 12Mbps (Full Speed Device)
Data format NRZI
Compatible connector Series B
Standard RS-232C specifications
Transmission method Asynchronous, duplex data transmission
Transmission speed 4800, 9600 (Selected using panel keys.)
Parity check Odd, Even, or None (Selected using panel keys.)
Data bits 7 or 8 bits (Selected using panel keys.)
Stop bits 1 or 2 bits (Selected using panel keys.)
Handshake Hardwire (power on) or XON/XOFF (Selected using panel keys.)
9-3 Interface Specifications
[Serial]
[USB]
[Serial connecter (RS-232C)]
NC
NC
NC
NC
NC
NC 13
12
11
10
9
8
7
6
5
4
3
2
1
DTR
25
14
15
16
17
18
19
20
21
22
23
24
NC
FG
TXD
RXD
RTS
CTS
DSR
SG
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
Signal
number
Terminal
number
Signal
number
Pin Connection
1
14
13
25
[USB connector]
Pin #2 Pin #1
Pin #3 Pin #4
Pin number Signal Remark
1 VCC Cable power
2 - Data
3 + Data
4 GND Cable ground
[XY-RS-34 serial cable connection]
Note: When making a serial connection using a cable other
than a XY-RS-34 cable from Roland DG Corp., use a
serial cable wired as shown in the figure below.
D-sub 9-pin (female) D-sub 25 pin (male)
