59
Key Function Range Default
MEMORY This calls up user-set cutting conditions matched to the USER1 to 8 –
tool and material in use.
FORCE This sets the force for the blade during cutting. 20 to 350 gf 50 gf
Perform a cutting test and set the conditions to match (10 gf step)
the loaded material and the installed blade.
SPEED This sets the speed for the blade during cutting. 1 to 85 cm/s 20 cm/s
Perform a cutting test and set the conditions to match (1 cm/s step)
the loaded material and the installed blade.
CURSOR These move the material and the carriage. – –
[
] [ ] [ ] [ ] When a menu is displayed, these change the menu
items and setting values.
PAUSE This pauses cutting. The PAUSE LED lights up while – –
operation is paused. Pressing this a second time
cancels the paused state. Holding down the [ENTER]
key for 0.5 seconds or longer while paused quits
cutting. This key is also effective when performing
material feed using the [AREA] menu.
MENU Pressing this repeatedly switches sequentially among – –
the presently set cutting conditions, the menu mode,
and the width-display screen.
Pressing this key when in the Menu mode returns you
to the cutting conditions screen.
ENTER This enables, runs, or stores the item shown on the – –
display.
ORIGIN Holding down this key for 0.5 seconds or longer sets – –
the origin point at the present blade position (the blade
center).
SHEET CUT Holding down this key for 0.5 seconds or longer cuts – –
off the material at the present position of the separating
knife. Press this to sever an already-cut piece of
material from a roll of material. Severing cannot be
performed while cutting is in progress.
TEST Holding down this key for 0.5 seconds or longer – –
performs a cutting test at the present blade position.
For more information, see “3-3 Adjusting the Blade
Force and Cutting Speed.”
MENU + Power on This sets the language for messages on the display.
/ENGLISH/ ENGLISH
(LANG.) You can select from among seven languages:
DEUT/FRANC/ESPAN
Japanese, English, German, French, Spanish, Italian,
ITAL/PORTOG
and Portuguese.
Power on This selects the type of material to use and enables the ROLL/PIECE/ –
(SELECT SHEET) setup state. For more information, see “4-2 Details of F-EDGE/R-EDGE
the Origin-point Location and Cutting Area.”
6-3 List of Functions
Control-key Functions
This describes the functions of the control keys when pressed.
To Next Page
