If a pinch roller is positioned over an area where there is no grit roller, the
message shown in the figure appears when you press the [ENTER] key.
If this occurs, lower the sheet loading levers and move the pinch rollers to the
proper positions above the grit rollers.
Reposition the material to match this new alignment, then lift the sheet loading
levers to hold the material in place.
When detecting the material size in step 4, if the material is misaligned and looks like it might come loose from the pinch rollers, or
actually does come loose, please reload the material.
4-5 Repeating the Same Cutting
The Replot feature lets you repeat cutting multiple times using the same cutting data, without having to send data from the computer
each time.
The Replot feature performs cutting using all the data stored in the machine's replot memory. This means that when you perform
replotting, then before you send the data to be replotted from the computer, you need to follow the steps below to delete the data in
the replot memory.
1
Press the [MENU] key several times, until the screen
shown in the figure appears.
2
Press the [ ] key several times.
If “NO DATA” is displayed here, skip ahead to step 4.
Send the data you want to replot from the computer, then follow the steps below to use the operation panel to perform replotting.
1
Carry out steps 1 and 2 above.
2
Press the [ ] key.
Pressing the [ENTER] key starts replotting.
4
Press the [MENU] key to go back to the screen shown
in the figure.
3
Press the [ ] key .
Use the [
] and [ ]keys to select [CLEAR], then
press the [ENTER] key to delete the data in the replot
memory.
BAD POSITION
UNSETUP
20cm/s
50gf 0.250mm A
REPLOT
DATA EXISTS
REPLOT
*CLEAR
REPLOT
DATA EXISTS
REPLOT
*START
