51
4-10 Performing Test Feed of Material Automatically
This makes the setting for performing test feed of the material automatically before cutting starts. It is intended to prevent motor
errors or misalignment due to roll material being pulled out at the feed rate used during cutting. The test feed is performed for the
required distance as determined by the size of the cutting data.
Performing test feed also lets you check to ensure that the material is not loaded at an angle.
This setting is turned off in the following cases.
- When the selection for [SELECT SHEET] is “PIECE” or “TRAILING EDGE.”
- When the front-loading feature is used.
(see “4-4 Loading Flat Material (Standard-size Material, Cut Material, Etc.)” and “4-6 Front Loading.”)
You make this setting using the CAMM-1 driver.
1
Open the CAMM-1 driver Properties window, click the [Options] tab, then in “Before Cutting,” select [Feed before Cutting].
2
Click [OK] to close the CAMM-1 driver Properties window.
4
Press the [MENU] key to go back to the screen shown in the figure.
3
Make sure the brake is released, then send cutting data from the computer.
Note that data requiring a lengthy amount of material feed may tend to cause misalignment.
To Next Page
