67
Make sure the power to the unit is
off before attempting to replace the
separating knife.
Doing so may result in injury.
7-3 How to Replace the Separating Knife
1
Switch off the power to the machine.
If the separating knife is not sharp enough to cut attractively, replace it with the replacement knife included with this machine.
Follow the steps below to replace the knife.
3
Replace with a new knife.
2
Remove the separating knife.
(1) Loosen the screw until it slips out.
(2) Grasp the screw portion, and slowly pull it out in
the direction of the arrow.
* Do not pull back while doing this.
4
Install the separating knife.
(1) Grasp the screw portion and slowly insert it into
the groove.
* Take care to ensure that the knife does not slip
(2) Tighten the screw.
Positioning groove
The knife is secured in place
by the magnet.
* If the blade remains in the carriage, use tweezers to remove it.
(2)
(1)
(2)
(1)
To Next Page
