34
4-2 Details of the Origin-point Location and Cutting Area
The Location of the Origin Point Immediately After Loading Material
With this machine, the initial origin point is determined when you load material and press the [ENTER] key. This origin point differs
according to the selection made for [SELECT SHEET] on the operation panel when loading material.
[ROLL] Set near the left-hand pinch roller
[F-EDGE] Set at the front left edge of the material
[R-EDGE] Set at the inner left edge of the material (When using the “Front loading”)
[PIECE] Material size is detected and the origin is set at the lower-left area of the material
For more information, see the following page.
* When [ROTATE] is set to [90deg], the initial origin point is set at the lower right with the X and Y axes rotated 90 degrees.
To Next Page
