10
Before Using the VC-30HD
The VC-30HD supports the following formats.
fig.conversion-table.eps
* The output frame rate will be the same as the input frame rate.
The VC-30HD does not support up/down scalling, interlace/progressive (I/P) conversion, or frame
rate conversion. The [OUTPUT FORMAT] indicators flash when the input and output formats are not
compatible, such as the scenarios shown below. No output is possible while the [OUTPUT FORMAT]
indicators are flashing.
• When 1080i component input is selected as the source and DV is selected as the output format.
• When NTSC S-Video input is selected as the source and HDV is selected as the output format.
Attach the included rubber feet to the bottom panel if necessary. Attach the rubber feet at
the locations shown below. Affix so as to block the four holes on the bottom panel.
* When turning the unit upside down, handle with care to avoid dropping the unit, allowing it to
fall or tip over, or damaging the controls.
fig.rubber-foot-location.eps
Supported Formats
About Rubber Feet
INPUT OUTPUT
1080/59.94i, 50i, 23.98PsF
720/59.94p, 50p
576/50p, 480/59.94p
Component/HDMI
576/50i, 480/59.94i
i.LINK(Rear), USB
HDV, MPEG-2
DV, MPEG-2
Composite/S-Video
576/50i, 480/59.94i
i.LINK (Rear), USB
DV, MPEG-2
i.LINK (Front)
HDV, DV, MPEG-2
i.LINK (Rear), USB
Thru Output
