Main Specifications
Codec
HDV
Video Format
Audio Format
MPEG-2 Video, 8 bits, 4:2:0
1440 x 1080/59.94i, 50i, 23.98p (25Mbps)
1280 x 720/59.94p, 50p (18.3Mbps)
720 x 480/59.94p, 720 x 576/50p (18Mbps)
MPEG-1 Audio Layer 2, 16 bits/48kHz, 2ch (384Kbps)
Video Format
Audio Format
720 x 480/59.94i (NTSC), 720 x 576/50p (PAL)
Linear PCM, 16 bits/48kHz, 2ch
MPEG-2
Video Format
(Default Setup)
Audio Format
MPEG-2 Video, 8 bits, 4:2:0
1920 x 1080/59.94i, 50i, 23.98p (35Mbps)
1280 x 720/59.94p, 50p (35Mbps)
720 x 480/59.94p, 720 x 576/50p (35Mbps)
720 x 480/59.94i, 720 x 576/50i (9Mbps)
MPEG-1 Audio Layer 2, 16 bits/48kHz, 2ch (384Kbps)
Input Connectors and Signals
HDMI
Video Format
Audio Format
1080/59.94i, 50i
720/59.94p, 50p
576/50p, 50i
480/59.94p, 59.94i
Linear PCM, 16 - 24 bits/32 - 48kHz, 2ch
Connector Type A (19 pins) x 1
Compo-
nent
Video Format
1080/59.94i, 50i, 23.98PsF
720/59.94p, 50p
576/50p, 50i
480/59.94p, 59.94i
Connector BNC type x 1 group
Signal Level Luminance Signal : 1.0 Vp-p, Chrominance Signal : 0.7 Vp-p
Impedance 75 ohms
Compo-
site
Video Format
480/59.94i (NTSC), 576/50i (PAL)
Connector BNC type x 1 (combinations use with Y of component)
Signal Level 1.0 Vp-p
Impedance 75 ohms
S-Video
Video Format 480/59.94i (NTSC), 576/50i (PAL)
Connector 4 pins mini DIN type x 1
Signal Level Luminance Signal : 1.0 Vp-p
Chrominance Signal : 0.286 Vp-p (NTSC), 0.3 Vp-p (PAL)
Impedance 75 ohms
DV
