32
Appendices
fig.dimension.eps
*
When using the holes in the side panel to secure the unit in place, use screws measuring 3 mm in
diameter and whose length is no more than 8 mm from the surface of the side panel.
Dimensions
7
Unit :
mm
189.6
11.8
41.8
146
31
33
