28
Converting Signals
Use the button in the [AUDIO INPUT] section on the front panel and the selector switch
on the rear panel to select the audio source. Possible selections are shown below.
fig.audio-source-select.eps
[RCA] + [ANALOG]
The [AUDIO (L/R)] connectors on the front panel are enabled.
[RCA] + [AES/EBU TIMECODE]
The [AUDIO (L/R)] connectors on the front panel are enabled. You can also input
timecode from the [TIMECODE] connector on the rear panel.
[XLR] + [ANALOG]
The analog [AUDIO IN] connectors on the rear panel are enabled.
[XLR] + [AES/EBU TIMECODE]
The [AES/EBU] connector is enabled. You can also input timecode from the [TIMECODE]
connector on the rear panel.
Audio Source Settings
To Next Page
