Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
31
Solid Green
PoE is enabled.
Blinking Green
(3 Hz)
PoE overload occurs.
LED Mode Button
The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates the switching status. Press the LED
Mode button, and the LED Mode indicator will turn yellow, indicating the PoE status. Press the LED Mode button again, the indicator
switches to indicating the switching status.
If you want to switch the LED mode, press the button for over two seconds.
1.9 RG-S5300-24GT4XS-P-E
Specifications
Model
RG-S5300-24GT4XS-P-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
 SFP+ Port:
 SFP Modules and SFP BIDI Modules
 SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
 See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Built-in Power Supply
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 6 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
All RJ45 ports are PoE+ capable and each port provides up to 30 W of power.
Maximum PoE Output: 370 W
The PoE+ port is compliant with both the PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards.
The maximum number of PoE devices supported by the switch is determined by the available
PoE consumption of the switch and the actual PoE consumption of each device.
The PoE port is compliant with Alternative A.
Power Consumption
Without PoE Load: < 65 W
