Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
51
Alarming
When a power fault occurs, the output status LED turns off.
LED
Function
Color
Status
Output Status LED
Off
The power supply module is not connected with a power
cord.
Solid Red
A power output error occurs, including fan fault, output
short-circuit, output overcurrent protection, output
overvoltage protection, power supply failure and overheat
protection.
Solid Green
The power supply module is outputing power normally.
1.13.5 RG-PD600I-P-F Module
The RG-S5310-24GT4XS-P-E and RG-S5310-48GT4XS-P-E switches support the RG-PD600I-P-F power module. The RG-PD600I-P-F
module is a DC module (DC input and DC output) providing an output voltage of 56 V and an output power of up to 600 W (PoE power:
370 W).
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules
are used, the switch works in the power redundancy mode. The switch supports 1+1 power redundancy when the PoE power
consumption is less than 370 W.
At least one power supply module is required. If any slot is unoccupied, install a filler panel to enable proper airflow.
Specifications
Item
Specification
Power Supply Model
RG-PD600I-P-F
Switch Model
RG-S5310-24GT4XS-P-E, RG-S5310-48GT4XS-P-E
Rated Input Voltage Range
DC Input: -48 V DC to -60 V DC
Maximum Input Voltage
Range
DC Input: -38 V DC to -75 V DC
Maximum Input Current
20 A
Output Voltage
56 V
Maximum Output Current
10.72 A
Maximum Output Power
600 W
PoE Power Consumption
370 W (Dual power supply modules: 740 W)
Dimensions (W x D x H)
196 mm x 90 mm x 40 mm (7.72 in. x 3.54 in. x 1.57 in.)
Weight
0.9 kg (1.98 lbs.)
Operating Temperature
-10°C to 55°C (14°F to 131°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Relative Operating
Humidity
5% to 95% RH (non-condensing)
Relative Storage Humidity
5% to 95% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Features
