Ruijie 5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
50
1.13.4 RG-PA600I-P-F Module
The RG-S5310-24GT4XS-P-E and RG-S5310-48GT4XS-P-E switches support the RG-PA600I-P-F power module. The RG-PA600I-P-F is an
AC module (AC/HVDC input and DC output) providing an output voltage of 56 V and an output power of up to 600 W (PoE power: 370
W).
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules
are used, the switch works in the power redundancy mode. The switch supports 1+1 power redundancy when the PoE power
consumption is less than 370 W.
At least one power supply module is required. If any slot is unoccupied, install a filler panel to enable proper airflow.
Specifications
Item
Specification
Power Supply Model
RG-PA600I-P-F
Switch Model
RG-S5310-24GT4XS-P-E, RG-S5310-48GT4XS-P-E
Rated Input Voltage Range
AC Input: 100 V AC to 240 V AC,50 Hz/60 Hz
HVDC Input: 240 V DC
Maximum Input Voltage
Range
AC Input: 90 V AC to 264 V AC, 47 Hz/63 Hz
HVDC Input: 192 VDC to 288 VDC
Maximum Input Current
8 A
Output Voltage
56 V
Maximum Output Current
10.72 A
Maximum Output Power
600 W
PoE Power Consumption
370 W (Dual power supply modules: 740 W)
Ground Leakage Current
≤ 3.5 mA
Dimensions (W x D x H)
196 mm x 90 mm x 40 mm (7.72 in. x 3.54 in. x 1.57 in.)
Weight
0.9 kg (1.98 lbs.)
Operating Temperature
-10°C to 55°C (14°F to 131°F)
Storage Temperature
-40°C to +70°C (-40°F to 158°F)
Relative Operating
Humidity
5% to 95% RH (non-condensing)
Relative Storage Humidity
5% to 95% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Features
Features
Benefit
Conformal Coating
Moisture-proof, salt spray-proof, mold-proof, insulation-proof and leak-proof
Protection
Undervoltage protection, output overcurrent protection, output overvoltage protection and output
short circuit protection
I2C Communication
The switch can communicate with the power supply module through I2C.
Power Redundancy
System supports 1+1 power redundancy when the power consumption is less than 370 W. Dual power
supply modules are connected in parallel for current sharing.
Hot Swapping
In the power redundancy mode, the power supply module can be replaced when the system is
powered on.

Ruijie 5310-E Series Specifications

General

Brand	Ruijie
Model	5310-E Series
Category	Switch
Language	English
