Ruijie Reyee RG-NBR-E Series User Manual

Cookbook Upgrade and Maintenance
133
4.1.2 Logging In Through the Console Port
Application Scenario
To enter the CLI for configuration management, you can connect the console port (configuration port) of the
router using a console cable, and enter the CLI using software such as HyperTerminal or SecureCRT. The RG-
NBR-E series router allows management through the console port by default.
Tools
 PC with COM port: The COM port on the PC is usually behind the chassis near the monitor interface. There
are nine pins on the interface, as shown in Figure 4-2. For a terminal without a COM port (such as a laptop),
prepare a COM-to-USB cable or use a Type 2 console cable.
Figure 4-2 COM port
Figure 4-3 COM-to-USB cable
 Console port: a console port is an interface marked with "Console" on the front panel of the device.
