4. Troubleshooting
4-1 Check-up Window Description
No. Function No. Function
1
CN22 do wnload (PC)
(SMW200-10 black)
6Set up the number of connected outdoor units
2
MICOM. download (AS-PRO)
(SMW200-07P white)
7
For checking indoor unit communication
(YW396-02P r ed)
3 ERROR DISPLAY 8
Transmitter 12V
(YW396-02P blue)
4
State Check
(SMW250-04P red)
9Outdoor Unit Tact Switch
5 EEPROM SOCKET 10 Outdoor Unit Dip Switch
3
6
8
7
4
9
1
5
2
10

Samsung AM250FNBFEB/EU Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	15.88 mm
Liquid hose diameter	9.52 mm
Refrigerating medium	R410A
Air conditioner functions	Heating
Heating capacity (nominal)	85300 BTU/h
Heating capacity in watts (max)	25000 W
Cooling capacity in watts (nominal)	- W
Operating temperature (heating) (T-T)	-20 - 24 °C
AC input voltage	220-240 V
Current (heating)	23.1 A
AC input frequency	50-60 Hz
Design load (cooling)	- kW
Energy efficiency scale	A+ to G
Power consumption (heating) (max)	5000 W
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Indoor unit type	Wall-mountable
Indoor unit depth	330 mm
Indoor unit width	518 mm
Indoor unit height	1210 mm
Indoor unit weight	104000 g
Indoor units quantity	1
Indoor unit package depth	426 mm
Indoor unit package width	652 mm
Indoor unit package height	1289 mm
Indoor unit package weight	107000 g
Indoor unit sound power level	42 dB
Indoor unit noise level (high speed)	61 dB
Outdoor unit noise level	- dB
