Troubleshooting
4-100 Samsung Electronics
1. Inspection Method
4-4-56 Sump Sensor Error Due to Protection Control
No
Is the sensor connector
properly connected to PCB?
Is the sensor displaying
the temperature normally?
Is the sensor properly attached to
the sensor holder below the compressor?
Refer to the solution method
for the
liquid-compression prevention error (E477).
Re-connect and check the connector.
Yes
Yes
Yes
No
No
Re-attach and check sensor.
Check by referring to the other temperature
sensor problem check
-up methods.
Outdoor Unit Display
Indoor Unit Display
×(Operation)
(Reservation) (Blast) (Filter) ×(Defr ost)
Judgment Method t.BJOUBJOTVNQUFNQFSBUVSFPG¡$PSNPSFGPSGJWFNJOVUFT
Special Cause t$PNQSFTTPSMPBEJOHGBVMUZTVNQUFNQFSBUVSFTFOTPSGBVMUZ

Samsung AM250FNBFEB/EU Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	15.88 mm
Liquid hose diameter	9.52 mm
Refrigerating medium	R410A
Air conditioner functions	Heating
Heating capacity (nominal)	85300 BTU/h
Heating capacity in watts (max)	25000 W
Cooling capacity in watts (nominal)	- W
Operating temperature (heating) (T-T)	-20 - 24 °C
AC input voltage	220-240 V
Current (heating)	23.1 A
AC input frequency	50-60 Hz
Design load (cooling)	- kW
Energy efficiency scale	A+ to G
Power consumption (heating) (max)	5000 W
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Indoor unit type	Wall-mountable
Indoor unit depth	330 mm
Indoor unit width	518 mm
Indoor unit height	1210 mm
Indoor unit weight	104000 g
Indoor units quantity	1
Indoor unit package depth	426 mm
Indoor unit package width	652 mm
Indoor unit package height	1289 mm
Indoor unit package weight	107000 g
Indoor unit sound power level	42 dB
Indoor unit noise level (high speed)	61 dB
Outdoor unit noise level	- dB
