Product Specifications
2-18 Samsung Electronics
Indoor Unit(cont.)
QConsole type
Model
AM022KNJDEH/TK AM028FNJDEH/TK AM036FNJDEH/TK AM045KNJDEH/TK AM056FNJDEH/TK
Power Supply ø/V/Hz
1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW
2.2 2.8 3.6 4.5 5.6
Btu/h
7,500 9,600 12,300 15,400 19,100
Heating*
3)
kW
2.5 3.2 4.0 5.0 6.3
Btu/h
8,500 11,000 13,600 17,100 21,400
Condensate
(with High fan speed)
Liters/h
0.96 1.75 -
Power
Input W
16.0 30
*5)
35
*5)
36.0 62
*5)
Running Current A
0.13 0.25
*5)
0.29
*5)
0.30 0.49
*5)
Sound Level
Sound Pressure
(Cooling / Heating)*
4)
dB(A)
38/39 41/43 42/44 48/49 49/51
Fan
Type -
Turbo Fan Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor
Model -
SIC-55CV-F137-2 SIC-55CV-F137-2 SIC-55CV-F137-2 SIC-55CV-F137-2 SIC-55CV-F137-2
Type -
BLDC BLDC BLDC BLDC BLDC
Output W
37 37.0 37.0 37 37.0
Airflow Rate
Cooling (High) m
3
/min
5.8
*5)
7.76
*5)
8.67
*5)
11.0
*5)
13.0
*5)
Heating (High) m
3
/min
6.3
*5)
7.22
*5)
8.89
*5)
11.3
*5)
13.5
*5)
Refrigerant
Type -
R410A R410A R410A R410A R410A
Control Method -
EEV EEV EEV EEV EEV
Temperature Control -
Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices -
Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm
12.7 12.7 12.7 12.7 12.7
Drain ø, mm
ID 18 hose ID 18 hose ID 18 hose ID 18 hose ID 18 hose
Weight
Net Weight kg
16.0 16.0 16.0 16.0 16.0
Shipping Weight kg
21.0 21.0 21.0 21.0 21.0
Dimensions
Net Dimensions (W x H x D) mm
720x620x199 720x620x199 720x620x199 720x620x199 720x620x199
Shipping Dimensions (W x H x D) mm
810x710x295 810x710x295 810x710x295 810x710x295 810x710x295
Functions
Auto Restart -
OOOOO
Auto Swing -
OOOOO
Group/Individual Control -
OOOOO
External Contact Control -
OOOOO
Trouble Shooting by LED -
OOOOO
Standard
Accessories
Installation Manual -
OOOOO
Operation Manual -
OOOOO
Pattern Sheet for Installation -
XXXXX
Flexible Drain Hose -
OOOOO
Filter / Safety Grille -
Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Wireless Remote Controller
ARH-1378(DB93-
07547B)
ARH-1378(DB93-
07547B)
ARH-1378(DB93-
07547B)
ARH-1378(DB93-
07547B)
ARH-1378(DB93-
07547B)
Optional
Accessories
Wireless Remote Controller -
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller
Simplified -
MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface
Module
-
MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
