Product Specifications
Samsung Electronics 2-15
Indoor Unit(cont.)
QBig Duct
Model AM220FNHDEH/TK AM280FNHDEH/TK
Power Supply ø/V/Hz 1/220-240/50 1/220-240/50
Mode*
1)
HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 22.4 28.0
Btu/h 76,400 95,500
Heating*
3)
kW 25.0 31.5
Btu/h 85,300 107,500
Condensate (with High fan speed) Liters/h
Power
Input W 530 790
Running Current A 3.8 5.9
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 47 / 44 48 / 45
Fan
Type - Sirocco Fan Sirocco Fan
Motor
Model - DL-13875SSOB DL-13875SSOB
Type - BLDC BLDC
Output W
Airflow Rate
Cooling (High) m
3
/min 58 72
Heating (High) m
3
/min 58 72
External Static Pressure Standard(Min.~Max) mmH2O 15(5-25) 15(5-28)
Refrigerant
Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52
Gas (Flare) ø, mm 19.05 22.2
Drain ø, mm VP25(OD32, ID25) VP25(OD32, ID25)
Weight
Net Weight kg 89 89
Shipping Weight kg 99 99
Dimensions
Net Dimensions (W x H x D) mm 1,240x470x1,040 1,240x470x1,040
Shipping Dimensions (W x H x D) mm 1,507x558x1,155 1,507x558x1,155
Functions
Auto Restart - O O
Auto Swing - X X
Group/Individual Control - O O
External Contact Control - O O
Trouble Shooting by LED - X X
Standard
Accessories
Installation Manual - O O
Operation Manual - O O
Pattern Sheet for Installation - O O
Flexible Drain Hose - O O
Filter / Safety Grille - X X
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver
- MRK-A10 MRK-A10
Receiver Wire
- MRW-10A MRW-10A
Wired Remote
Controller
Simplified - MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14
Drain Pump MDP-N047SNC1D MDP-N047SNC1D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Samsung AM250FNBFEB/EU Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	15.88 mm
Liquid hose diameter	9.52 mm
Refrigerating medium	R410A
Air conditioner functions	Heating
Heating capacity (nominal)	85300 BTU/h
Heating capacity in watts (max)	25000 W
Cooling capacity in watts (nominal)	- W
Operating temperature (heating) (T-T)	-20 - 24 °C
AC input voltage	220-240 V
Current (heating)	23.1 A
AC input frequency	50-60 Hz
Design load (cooling)	- kW
Energy efficiency scale	A+ to G
Power consumption (heating) (max)	5000 W
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Indoor unit type	Wall-mountable
Indoor unit depth	330 mm
Indoor unit width	518 mm
Indoor unit height	1210 mm
Indoor unit weight	104000 g
Indoor units quantity	1
Indoor unit package depth	426 mm
Indoor unit package width	652 mm
Indoor unit package height	1289 mm
Indoor unit package weight	107000 g
Indoor unit sound power level	42 dB
Indoor unit noise level (high speed)	61 dB
Outdoor unit noise level	- dB
