Samsung CLP-775ND User Manual

Management tools_ 63
Smart Panel overview
If an error occurs while operating, you can check the error from the Smart
Panel. You can also launch Smart Panel manually.
Changing Smart Panel ‘s settings
Right-click in Linux or in Mac OS X click on the Smart Panel icon and select
Options. Select the settings you want from the Options window.
Using the Unified Linux Driver Configurator
Unified Driver Configurator is a tool primarily intended for configuring
machine devices. You need to install Unified Linux Driver to use Unified
Driver Configurator (See "Linux" on page 23).
After the driver is installed on your Linux system, the Unified Driver
Configurator icon will automatically be created on your desktop.
Opening the Unified Driver Configurator
1. Double-click the Unified Driver Configurator on the desktop.
You can also click the startup menu icon and select Samsung Unified
Driver > Unified Driver Configurator.
2. Click each button on the left to switch to the corresponding configuration
window.
To use the on screen help, click Help.
3. After changing the configurations, click Exit to close the Unified Driver
Configurator.
Printers configuration
Printers configuration has the two tabs: Printers and Classes.
Printers Tab
View the current system’s printer configuration by clicking on the
machine icon button on the left side of the Unified Driver Configurator
window.
Macintosh
Click this icon the Smart Panel icon on the
menu bar.
Linux
Double-click the Smart Panel icon in the
Notification Area.
1
Toner Level You can view the level of toner remaining in each
toner cartridge. The machine and the number of
toner cartridge(s) shown in the above window
may differ depending on the machine in use.
Some machines do not have this feature.
2
Buy Now You can order replacement toner cartridge(s)
from online.
3
User’s Guide You can view the online User’s Guide.
This button opens the Troubleshooting
Guide when an error occurs. You can
directly open the troubleshooting section in
the user’s guide.
4
Printer Setting You can configure various machine settings in
the Printer Settings Utility window. Some
machines do not have this feature.
If you connect your machine to a network,
the SyncThru™ Web Service window
appears instead of the Printer Settings
Utility.
1
2
3
4
1 Printers
configuration
2 Ports
configuration
1
Switches to Printers configuration.
2
Shows all of the installed machine.

Samsung CLP-775ND Specifications

General

Network ready	Yes
Supported network protocols (IPv4)	TCP / IPv4 / v6, SNMPv2 / v3, HTTP (S), DHCP / BOOTP
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	10 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Number of print cartridges	4
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3
Maximum internal memory	896 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Display	LCD
Total input capacity	500 sheets
Total output capacity	350 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Power consumption (standby)	8 W
Power consumption (printing)	60 W
Sustainability certificates	ENERGY STAR
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 7 (32 bit, 64 bit) / 2008 (32 bit, 64 bit) / Vista (32 bit, 64 bit) / 2003 (32 bit, 64 bit) / XP (32 bit, 64 bit) / 2000 [Linux] RedHat Enterprise Linux WS 4, 5 (32 / 64 bit), Fedora 5 ~ 13 (32 / 64 bit), SuSE Linux 10.1 (32 bit), OpenSuSE 10.2, 10.3, 11.0, 11.1, 11.2 (32 / 64 bit), Mandriva 2007, 2008, 2009, 2009.1, 2010 (32 / 64 bit), Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10, 10.04 (32 / 64 bit), SuSE Linux Enterprise Desktop 10, 11 (32 / 64 bit), Debian 4.0, 5.0 (32 / 64 bit) [MAC] Mac OS X 10.3 ~ 10.6 [Unix] Sun Solaris 9, 10 (x86, SPARC), HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC, Itanium), IBM AIX 5.1, 5.2, 5.3, 5.4

Weight and Dimensions

Dimensions (WxDxH)	446 x 481 x 464 mm
