MD / VA
Events of motion detection and video analysis can be set to trigger event signal output.
1. From the Setup menu, select the
<Event (
)> tab.
2. Click <MD / VA>.
3. Set whether or not to <Enable>.
4. According to your purpose, select from
motion detection and intelligent video
analysis.
5. Set <Sensitivity>, <Size> and <Area>.
When selected Intelligent Video
Analysis, set <Analytics> too.
6. Select use of <Overlay>.
• Detection result overlay : The
detection result is indicated on the
video.
• Analytics rule overlay : The analysis
rules are displayed on the video.
7. Specify the activation time and
activation condition.
`
For more information about <Activation
time> and <Action>, refer to “Alarm input”.
(page 120)
8. When done, click [Apply (
)].
setup screen
124_ setup screen
