To set the video analysis rules
`
Passing
1. Set the type to <Passing>.
2. On the screen, click on preferred
starting and ending point of the virtual
line, then a popup window appears.
3. Select the desired rule:
• Right: Detects motions of moving
from the left to the right, over the
virtual line.
• Left: Detects motions of moving from
the right to the left, over the virtual
line.
4. Click [OK].
5. To remove a defined rule, right click on the displayed virtual line to open popup
context menu and select [Delete] button.
`
Entering/Exiting
1. Set the type to <Entering/Exiting>.
2. On the screen, click four vertices to
define detection area and a popup
window appears.
3. Select the desired rule:
• Entering : Detects motions of moving
object whose center point entering
into the defined area, from outside of
the area.
• Exiting : Detects motions of moving
object whose center point exiting
from the defined area, from inside of the area to outside.
4. Click [OK].
5. To remove a defined rule, right click on the displayed side lines of the area to open
popup context menu and select [Delete] button.
English _129
● SETUP SCREEN
