installation & connection
34_ installation & connection
CONNECTING WITH OTHER DEVICE
J
`
The CVBS out terminal of the product is provided for easier installation, and is not recommended
for monitoring purposes.
AUDIO
IN
AUDIO
OUT
Monitor to install
Power
Ethernet
Monitor to install
Ethernet
Power
Grounding cable
