installation & connection
36_ installation & connection
Power Cable Specification for Each Model
In case of DC 12V Input:
Wire Type (AWG) #22 #20 #18
Cable Length (Max.)
SNB-6003
20m 32m 50m
SNB-6004
SND-6083
24m 38m 60m
SND-6084
In case of AC 24V Input:
Wire Type (AWG) #22 #20 #18
Cable Length (Max.)
SNB-6003
34m 55m 88m
SNB-6004
Network Cable Specification
Item Contents Remark
Connector RJ45
Ethernet 10/100Base-T 10/100 Mbps
Cable UTP Category 5e
Max Distance 100M
PoE Support IEEE 802.3af
Grounding the Product (SNB-6003/SNB-6004)
Connect the ground wire to the ground terminal which is located above the power input
terminal by using a screwdriver.
J
`
Grounding protects the product from a surge or lightning.
`
When grounding, make sure to turn the product’s power off.
Recommended Grounding Cable
• Length : Less than 3M
• Gauge : 18 AWG or bigger
Ex) UL1007 AWG 18/16, UL1015 AWG18/16/14/12, UL2468 AWG18/16/14
To Next Page
