appendix
146_ appendix
PRODUCT OVERVIEW
SNB-6003
Unit : mm (inch)
136.2(5.36")
73.1(2.88")
66.6(2.62")
Ø 6.5 HOLE (Ø 0.26")
14 (0.55")
56.1 (2.21")
Ø 1/4'-20 UNC-2B
