Sanyo PLC-XF47 Service Manual

VIDEO-IN < TP201(R)> VIDEO-IN < TP211(G)>
VIDEO-IN < TP221(B)>
PC-IN < TP201(R)> PC-IN < TP211(G)>
PC-IN < TP221(B)>
VIDEO-IN <TP201> V-SYNC PC_16STEP-IN<TP211>
PC_16STEP-OUT<TP531>
PC_R-OUT<TP501>
PC_G-OUT<TP531>
PC_B-OUT<TP561>
- 135 -
Electrical Adjustments
n
Waveforms
– 9 Sampling Phase A / D Clock 0 ~ 63 0 –
– 10 Pre Shoot Level Sub Sharpness 0 ~ 15 8 –
– 11 Over Shoot Level Sub Sharpness 0 ~ 15 8 –
– 12 Y Filter Setting Y Filter 0 ~ 7 5 –
– 13 C Filter Setting C Filter 0 ~ 7 5 –
– 14 NTSC / PAL Detect 0 : 64H / 1V 0 ~ 3 1
1 : 96H / 1V
2 : 128H / 1V
3 : 160H / 1V
Group
No.
Data
Range
Initial Value
Function
Item
No.
Item
PLC-XF47

Sanyo PLC-XF47 Specifications

General

Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	40 - 600 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	80 °
Keystone correction, horizontal	40 °
I/O ports	Analog (D-sub15), Serial in & Serial out (D-Sub 9 x 2)
Video out	UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA, MAC
Resolution	2359296 pixels
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	581 x 815.5 x 251.5 mm
Power requirements	200-240 V AC 9.7 A Max, 50 / 60 Hz
Connectivity technology	Wired
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Dot clock scanning frequency	230 MHz
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	1700 W

Weight and Dimensions

Weight	36500 g
