Sanyo PLC-XF47 Service Manual

- 90 -
Electrical Adjustments
Not designated PC COMPOSITE COMPONENT
140 - 0 Fans-A driving voltage adjustment ●
140 - 1 Fans-A driving voltage adjustment ●
140 - 2 Fans-B driving voltage adjustment ●
140 - 3 Fans-B driving voltage adjustment ●
140 - 4 Fans-C driving voltage adjustment ●
140 - 5 Fans-C driving voltage adjustment ●
140 - 6 Fans-D1 driving voltage adjustment ●
140 - 7 Fans-D1 driving voltage adjustment ●
140 - 8 Fans-D2 driving voltage adjustment ●
140 - 9 Fans-D2 driving voltage adjustment ●
140 - 10 Fans-D3 driving voltage adjustment ●
140 - 11 Fans-D3 driving voltage adjustment ●
140 - 12 Fans-D4 driving voltage adjustment ●
140 - 13 Fans-D4 driving voltage adjustment ●
141 - 0 Fans driving voltage adjustment (max/auto/min) ●
280 - 9 Common center adjustment--Green ●
280 - 10 Common center adjustment--Red ●
280 - 11 Common center adjustment--Blue ●
290 - 1 Setting LCD Panel R / L ●
660 - 0 Gain adjustment 1 (PC) ●
660 - 0 Gain adjustment 2 (Composite) ●
660 - 0 Gain adjustment 3 (Component) ●
     
2000 - 2 AV video signal adjustment (Y) ●
2000 - 3 AV video signal adjustment (C) ●
     
0 - 0 Temperature monitor IC5801 Read only ●
0 - 1 Temperature monitor IC2541 Read only ●
1 - 0 Atmospheric Pressure monitor IC886 Read only ●
10 - 0 RS232C Baud rate (0:9600 / 1:19200) ●
930 - 0 Lamp mode 4 Lamp Mode (See Note.) ●
930 - 1 Lamp mode Lamp 1-4 of 2 Lamp Mode (See Note.) ●
930 - 2 Lamp mode Lamp 2-3 of 2 Lamp Mode (See Note. ) ●
Group-no. Adjustment Item Adjustment Mode
●Service Mode Adjustment Menu

Sanyo PLC-XF47 Specifications

General

Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	40 - 600 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	80 °
Keystone correction, horizontal	40 °
I/O ports	Analog (D-sub15), Serial in & Serial out (D-Sub 9 x 2)
Video out	UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA, MAC
Resolution	2359296 pixels
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	581 x 815.5 x 251.5 mm
Power requirements	200-240 V AC 9.7 A Max, 50 / 60 Hz
Connectivity technology	Wired
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Dot clock scanning frequency	230 MHz
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	1700 W

Weight and Dimensions

Weight	36500 g
