-64-
Troubleshooting
No Sound
Check following steps.
Check IC5001 and peripheral circuit.
Check 5V power supply.
Check if the audio sig-
nal is observed at pins 7
and 15 of IC5001.
Check audio output circuit.
Check speaker, connection of the terminal “K8F”.
Yes
No
Check IC5031 and peripheral circuit.
Check the Mute signal at pin 1 of IC5301. The Mute signal is output from
pin 267 of IC 301<Scaler>. The OUT_DET signal is sent from Audio Out
terminal.
Mute-On: H at pin 267 of IC301, L at pin 1 of IC5031.
Check if the audio signal
is observed at pins 1 of
IC5031.
Yes
No
To Next Page
