KR5-XR20100, KS5-XR25100
-73-
Electrical Parts List
Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
ASSEMBLED BOARDS
FOR KR5-XR20100
!A1000 655 002 7764 ASSY,PWB,MAIN KR5AC
!A2200 655 002 7887 ASSY,PWB,POWER KR5AC
!A2300 655 002 8396 ASSY,PWB R/C KR5AC
FOR KS5-XR25100
!A1000 655 002 8433 ASSY,PWB,MAIN KS5AC
!A2200 655 002 7887 ASSY,PWB,POWER KR5AC
!A2300 655 002 8396 ASSY,PWB R/C KR5AC
OUT OF CIRCUIT BOARD
 L602 945 003 3835 CORE,FERRITE
 L603 945 003 3835 CORE,FERRITE
 L604 945 003 3835 CORE,FERRITE
!LP900 610 345 2456 COMPL, OPTICAL LAMP-KR5AC
!A901 645 099 5941 UNIT,BALLAST
A901A 610 345 4276 CABLE,BALLAST KR5AC
!FN001 645 100 1900 MOTOR,BLW DC
!FN002 645 100 1917 MOTOR,FAN DC
!FN003 645 100 1894 MOTOR,BLW DC
!FN004 645 100 1887 MOTOR,BLW DC
!FN005 645 100 1887 MOTOR,BLW DC
SP901 652 002 4397 SPEAKER,8
 SW902 645 097 3925 SWITCH,MICRO 1P-2T
FOR KR5-XR20100
655 002 7764 ASSY,PWB,MAIN KR5AC
FOR KS5-XR25100
655 002 8433 ASSY,PWB,MAIN KS5AC
TRANSISTOR
Q1001 406 021 7804 TR 2SC4617
Q1002 406 021 7804 TR 2SC4617
Q1003 305 217 7815 TR HN1B04FE-Y TE85L
Q1004 305 217 7815 TR HN1B04FE-Y TE85L
Q1005 406 021 7804 TR 2SC4617
Q1006 305 217 7815 TR HN1B04FE-Y TE85L
Q1007 406 021 7804 TR 2SC4617
Q1008 406 021 7804 TR 2SC4617
Q1010 406 021 7804 TR 2SC4617
Q1011 406 021 7804 TR 2SC4617
Q1012 406 021 7804 TR 2SC4617
Q2001 406 021 7804 TR 2SC4617
Q2025 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q4012 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q4014 305 217 7815 TR HN1B04FE-Y TE85L
Q5031 405 221 7914 TR HN1C01FE-Y
Q5033 406 021 7804 TR 2SC4617
Q5035 405 221 7914 TR HN1C01FE-Y
Q5061 405 221 7914 TR HN1C01FE-Y
Q5062 405 221 7914 TR HN1C01FE-Y
Q5306 406 021 7804 TR 2SC4617
Q5700 305 217 7815 TR HN1B04FE-Y TE85L
Q5701 305 174 1819 TR CPH3424-TL-E
Q5702 305 047 9010 TR 2SB1204-S-TL-E
Q5703 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5751 305 217 6917 TR TPC6107 TE85L
Q5752 406 021 7804 TR 2SC4617
Q5830 305 217 6917 TR TPC6107 TE85L
Q5840 406 021 7804 TR 2SC4617
Q6845 405 221 7914 TR HN1C01FE-Y
Q6846 405 221 7914 TR HN1C01FE-Y
Q7801 405 221 7914 TR HN1C01FE-Y
Q7802 405 221 7914 TR HN1C01FE-Y
Q7812 305 217 8515 TR RSQ025P03-TR
Q7813 305 217 7815 TR HN1B04FE-Y TE85L
Q7842 305 217 7815 TR HN1B04FE-Y TE85L
Q7862 305 217 8515 TR RSQ025P03-TR
Q7864 305 217 7815 TR HN1B04FE-Y TE85L
INTEGRATED CIRCUIT
IC1051 409 697 3913 IC LE24C023M-TLM-E
IC1371 410 656 8600 IC 24AA64T-I/MS
IC1424 410 666 5804 IC UPC358GR-9LG-E1-A
IC301 309 670 8419 IC PW190-10L
IC302 309 487 5727 IC TC7SZ125FU
IC3801 409 699 2815 IC MAX232ECPWR
IC3852 309 246 9710 IC LA6358NM-TE-L-E
IC4001 410 686 4702 IC EL5306IUZ-T7
IC4701 309 428 8428 IC TC7WT125FU-TE12L
IC4891 309 395 5915 IC TC7SH00FU-(TE85L)
IC5001 410 693 3903 IC LC75344M-D-TLM-E
IC5031 309 594 1916 IC LM4889MMX
IC5081 309 578 6210 IC PQ1M505M2SPQ
IC5621 410 651 0104 IC R1131D101B-TR-F
IC5821 409 689 2115 IC MP2106DK
IC5841 409 694 5316 IC TJ3965D-2.5V-8L
IC5861 409 689 2115 IC MP2106DK
IC592 309 461 7822 IC PQ20WZ11
IC7811 309 675 1316 IC FA7703V-H1
IC7841 309 461 7822 IC PQ20WZ11
IC801 410 691 6005 IC M29W320ET70N6EKR5AC
IC841 409 699 3010 IC PT7M7809STE
IC8801 410 691 1901 IC PIC18F67J60-I/PT-KR5AC
IC8802 410 656 8600 IC 24AA64T-I/MS
IC8803 410 681 5506 IC LE25FU106BMA-TLM-H
IC9882 310 337 0605 IC HD74LVC14T
CAPACITOR
C1001 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C1002 303 392 1215 ELECT 47U M 6.3V
C1004 303 453 8917 CERAMIC 0.1U K 16V
To Next Page
