KR5-XR20100, KS5-XR25100
Electrical Parts List
-72-
Electrical Parts Location
● Assemblied Boards
SW902
Lamp Cover SW
A2300
R/C Board
FN002
Cooling Fan
LP900
Lamp Ass’y
FN004
Cooling Fan
● Out Of Circuit Board
SP901
Speaker
A901
Ballast Board
A2200
Power Board
FN003
Cooling Fan
SW601
Thermal Switch
FN005
Cooling Fan
A1000
Main Board
FN001
Cooling Fan
