Mechanical Parts List

For KR5-XR20100

CABINET PARTS

C01 610 345 0049 ASSY,ADJ-KR5AC

C02 610 346 5432 CAB BTM-KR5AC

C03 610 346 8082 CABINET TOP SERVICE-KR5AD

C04 610 344 9982 BUTTON CONTROL-KR5AC

C05 610 346 8099 COVER ,LP SERVICE-KR5AC

C06 610 344 9999 DEC INLAY LED-KR5AC

C07 610 345 0018 DEC INLAY RC-KR5AC

C08 610 345 8717 DEC RING-KR5BC

C09 910 325 2477 DEC LEG-PT5EC

C10 610 345 0032 PANEL AV-KR5AC

C11 610 347 7961 PANEL NET FRONT-KR5AC

C12 610 346 5906 PANEL NET BACK A-KR5AC

(Air filter(back))

C13 610 345 0025 COVER LENS-KR5AC

CHASSIS PARTS

M01 610 345 0087 HOLDER LAMP BASE-KR5AC

M02 610 345 2371 HOLDER POWER-KR5AC

M03 610 343 3721 MTG RELAY OUT-KR5AC

M04 610 343 3738 MTG COND OUT-KR5AC

M05 610 345 0193 MTG DUCT BTM IN LAMP

M06 610 345 0179 MTG DUCT TOP IN LP-KR5AC

M07 610 346 1076 MTG DUCT PANEL-KR5AC

M08 610 345 0223 SPACER PANEL NET-KR5AC

(Air filter(front))

M09 610 343 3707 OPTICAL TOP-KR5AC

M10 610 343 3714 OPTICAL TOP -KR5AC

M11 610 343 2588 OPTICAL BASE-KR5AC

SCREWS

S01 411 031 9304 SCR BIN 3X8

S02 411 179 8801 SCR S-TPG BIN 3X10

S03 412 077 8108 SPECIAL SCREW-2.5X6

S04 411 191 6304 SCR BIN 2.5X8

S05 411 192 6709 SCR PAN+SW+W 3X10

S06 411 033 2600 SCR FLT 2x4

OPTICAL PARTS

L01 610 345 6614 ASSY,PNL/PRISM-KR5AC

L03-R 645 101 2135 ASSY,LENS,CONDENSER(R)

L03-G 645 101 2142 ASSY,LENS,CONDENSER(G)

L03-B 645 101 2159 ASSY,LENS,CONDENSER(B)

L04 645 099 6993 LENS,PROJECTION

L05 645 096 4671 LENS,RELAY(OUT)

L06 645 099 0571 LENS,RELAY(IN)

L07 645 099 8447 LENS,INTEGRATOR(IN)

L08 645 099 8454 LENS,INTEGRATOR(OUT)

L09 645 099 8478 LENS,CONDENSER(OUT)

L10 945 086 6372 PRISM(PBS)

L11 645 096 4718 MIRROR(R)

L12 645 099 8492 MIRROR(B)

L13 645 100 5144 DICHROIC MIRROR (B)

L14 645 100 5151 DICHROIC MIRROR (G)

For KS5-XR25100
