Sanyo PLC-XT35 Service Manual

KP3-XT3500, KP3-XT35L00
-111-
Electrical Parts List
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLED BOARDS
! 610 335 3081 ASSY,PWB,MAIN KP3AL
! 610 335 3128 ASSY,PWB,A/V KP3AL
! 610 335 3166 ASSY,PWB,NETWORK JOINT KP3AL
! 610 335 3135 ASSY,PWB,R/C. FRONT KP3AL
OUT OF CIRCUIT BOARDS
L901 945 003 3835 CORE,FERRITE
L902 945 003 3835 CORE,FERRITE
LP901 610 335 8093 COMPL,OPTICAL LMP-KP3AL
*03* 945 003 3811 CORE,FERRITE
! A901 645 093 0980 UNIT,BALLAST
! BLST&LMP 610 339 2325 CABLE,BALLAST SERVICE KP3AL
!A902 645 093 0089 UNIT,POWER(AC)
! A903 645 093 0881 UNIT,POWER(DC)
! A904 645 093 0096 UNIT,POWER(FILTER)
! FN901 945 088 7049 MOTOR,FAN DC 3.36W
! FN902 945 088 7063 MOTOR,FAN DC 4.20W
! FN903 645 093 8481 MOTOR,BLW DC 2.76W
! FN904 645 093 8498 MOTOR,BLW DC 15.0W
! FN905 645 093 8504 MOTOR,BLW DC 15.0W
SP901 945 078 6106 SPEAKER,8
! SW901 645 089 4879 THERMOSTATS
! SW902 645 089 4916 SWITCH,PUSH
TH901 945 079 7775 SWITCH,THERMAL,THERMISTOR
TH902 945 079 7768 SWITCH,THERMAL,THERMISTOR
! FUSE 323 027 2605 FUSE 250V 10A
610 335 3081 ASSY,PWB,MAIN KP3AL
TRANSISTOR
Q1001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1051 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1052 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1061 305 217 5019 TR RN1117 TE85L
Q1351 305 211 1918 TR RJU002N06
Q1352 305 211 1918 TR RJU002N06
Q151 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q152 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q153 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q171 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q172 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q173 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q2801 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q2802 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q2851 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q2852 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
