Sanyo PLC-XT35 Service Manual

-98-
PIN NO. PORT NO. NAME DESCRIPTION I/O
1 OE1 CS1 PW190 Chip Select I
2 A1 THERM2_DETECT Temp. Sensor 2 Detection, H: Error, L: Normal I
3 A2 LENS_SENS_C Lens Shift Sensor (Left-Right Center), H: Center, L: Not Center I
4 A3 LENS_SENS_L Lens Shift Sensor (Left), L: End I
5 A4 LENS_SENS_R Lens Shift Sensor (Right), L: End
I
6 A5
LENS_SENS_D Lens Shift Sensor (Down), L: End I
7 A6 LENS_SENS_U Lens Shift Sensor (Up), L: End I
8 A7 THERM1_DETECT Temp. Sensor 1 Detection, H: Error, L: Normal I
9 A8 S_SW S-Terminal Detection, L: Inserted I
10 GND GND - -
11 Y8 D7 Data Bus 7 O
12 Y7 D6 Data Bus 6 O
13 Y6 D5 Data Bus 5 O
14 Y5 D4 Data Bus 4 O
15 Y4 D3 Data Bus 3 O
16 Y3 D2 Data Bus 2 O
17 Y2 D1 Data Bus 1 O
18 Y1 D0 Data Bus 0 O
19 OE2 OE2 Output Enable2 I
20 Vcc Vcc - -
PIN NO. PORT NO. NAME DESCRIPTION I/O
1 A1 FAN_DAC1 Fan Control Analog Output AO
2 A2 FAN_DAC2 Fan Control Analog Output AO
3 A3 FAN_DAC3 Fan Control Analog Output AO
4 A4 FAN_DAC4 Fan Control Analog Output AO
5 GND GND - -
6 SDA SDA IIC BUS SDA(5V) I/O
7 SCL SCL IIC BUS SCL(5V) I/O
8 Vcc Vcc - -
PIN NO. PORT NO. NAME DESCRIPTION I/O
73 P32 PJ_I/O_UART PJ-Net Command (PW:RXD) I
74 P33 M_TXD PJ-Net AirMouse TXD O
75 P34 Not Used I
76 P35 LENS_LR_PWM Lens Shift Left/Right PWM Output, L: Move, H: Stop O
77 P36 LENS_UD_PWM Lens Shift Up/Dwon PWM Output, L: Move, H: Stop O
78 P37 DAC_PWM PWM for Fan Control O
79 P38 NET_SW PJ-Net Power On/Off O
80 UVss Uvss - -
81 DMINUS DMINUS USB D- I/O
82 DPLUS DPLUS USB D+ I/O
83 UVdd33 UVdd33 - -
84 DVdd25 DVdd25 - -
85 XCS3 XCS3 Ext. Chip Select O
86 DVss DVss - -
87 DVss DVss - -
88 RSTMSK RSTMSK Internal Reset Mask I
89 DVdd33 DVdd33 - -
90 DVss DVss - -
91 P11 SCLK_I/O Configration Clock O
92 P12 SDATA_I/O Configration Data / FPGA Data Out O
93 P13 SDTO_I/O FPGA Data In I
94 P14 VD_RST Video Decoder(CXD3815) Reset L-H O
95 DVss DVss - -
96 DVss33 DVss33 - -
97 P15 W_RC_SW Wired RC Detectionm H: Not Inserted, L: Inserted I
98 P16 PRODUCT_OPT I
99 P17 INT_I/O Configration Status I
100 P18 DONE_I/O Configration Process End Signal I
Parallel Bus Input Expander Port Functions (TC74LCX541)
IIC Bus D/A Converter Port Functions (M62334)
Control Port Functions
