Sanyo PLC-XT35 Service Manual

-88-
Chassis Description
IC301
SCAN
CONVERTER
&
SYSTEM
CONTROL
<PW190>
KEY1
Wired RC
Jack
A2821
RC Pre-Amp.
A4051
RC Pre-Amp.
K30BK8S
R/C
AV JOINT
MAIN
FILTER_LED
28
26 28
118
K40EK30A
95 96 93 94
3 4
K28A K8G
1
Q2851 D2851
KEY2
126
KEY3
216
BOX_SW
R/C_PW W_R/C
W _R/C_SW
W _R/C_SW
R/C-FRONT
R/C-REAR
92 182
WARNING FILTER
LAMP_LED
Q2852 D2852
269
LAMP REPLACE
TEMP_LED
Q2853 D2853
184
WARNING TEMP
READY_LED
Q2854 D2854
91
POWER
POWER_LED
R/C_CTL0 R/C_CTL1
Q2856 D2856
Q2801 Q2802
346 214 2
2 5
1
53 52 97
4 6 3
7
D[0-7]
LAMP
Key Switches
IC2811
BUFFER
IC2801
BUFFER-SW
IC1801
I/O EXPANDER
<TE7783>
R/C ACTIVE R/C_CTL0 R/C_CTL1 NORMAL L L FRONT ONLY H L REAR ONLY L H WIRED H H
LED drive & RC control stage
