-96-
Control Port Functions
System Control I/O Port Functions (PW190)
PIN NO. PORT NO. NAME DESCRIPTION I/O
1 A1 SIPD Sil169 Power Down, Power Down: L O
10 A10 ZOOM- Zoom Drive -, On: H Off:L O
11 A11 3.3V_SW_EX 3.3V Power Supply On/Off Drive, Power On: H O
101 B2 MUTE Audio Mute, Mute On: H O
109 B10 FOCUS- Focus Drive -, On: H Off:L O
110 B11 5V_SW_EX 5V Power Supply On/Off Drive, Power On: H O
111 B12 SCS_PW 3wire Chip Select O
124 B25 TXD_PW UART TXD, Active:L O
99 C1 IN1R5 Red Pixel Input I
200 C10 FOCUS+ Focus Drive +, On: H Off:L O
201 C11 15V_SW_EX 15V Power Supply On/Off Drive, Power On: H O
202 C12 SDATA_PW 3Wire Data O
205 C15 S&H_LR Lens Shift R/L SW O
208 C18 HW2Wire DA2 IIC Bus SDA2, Active:L I/O
211 C21 HW2Wire CL1 IIC Bus SCL1, Active:L I/O
98 D1 IN1R8 Red Pixel Input I
191 D2 IN1R6 Red Pixel Input I
276 D3 IN1R3 Red Pixel Input I
278 D5 FAN_SW_2EX Fan3 Control Signal, Lamp Valtage 40V or more: H Lamp Valtage 40V or less: L O
284 D11 ZOOM+ Zoom Drive +, On: H Off:L O
285 D12 FAN_SW_1EX Fan Control SW, On: H O
290 D17 HW2Wire CL2 IIC Bus SCL2, Active:L I/O
293 D20 HW2Wire SC0 IIC Bus SCL0, Active:L I/O
294 D21 HW2Wire DA1 IIC Bus SDA1, Active:L I/O
296 D23 LENS_UD_SW Lens Up/Down SW O
97 E1 IN1G2 Green Pixel Input I
190 E2 IN1R9 Red Pixel Input I
275 E3 IN1R7 Red Pixel Input I
352 E4 IN1R4 Red Pixel Input I
353 E5 IN1R2 Red Pixel Input I
362 E14 BALAST_AC_EX Lamp Control Signal, On: H O
363 E15 LAMP_DC_ON_EX Ballast Power Control SW O
368 E20 RXD_PW UART RXD, Active:L I
96 F1 IN1G6 Green Pixel Input I
189 F2 IN1G3 Green Pixel Input I
420 F5 IN1G4 Green Pixel Input I
95 G1 IN1G9 Green Pixel Input I
188 G2 IN1G7 Green Pixel Input I
273 G3 IN1G5 Green Pixel Input I
419 G5 IN1G8 Green Pixel Input I
94 H1 IN1B3 Blue Pixel Input I
187 H2 IN1B2 Blue Pixel Input I
349 H4 IN1B6 Blue Pixel Input I
418 H5 IN1B8 Blue Pixel Input I
93 J1 IN1B9 Blue Pixel Input I
186 J2 IN1B7 Blue Pixel Input I
271 J3 IN1B5 Blue Pixel Input I
348 J4 IN1B4 Blue Pixel Input I
92 K1 FILTER_LED Filter LED, On: H O
185 K2 PDO DVI Output Power Down Mode,PowerDown:L O
347 K4 IN1PEN Pixel Data Enable I
91 L1 READY_LED Ready LED, On: H O
184 L2 TEMP_LED Warning Temp. LED, On: H O
269 L3 LAMP_LED Lamp Replace LED, On: H O
346 L4 POWER_LED Power LED, On: H O
90 M1 XSTNDBYEN Standby Mode On/Off for I/O Exp. On: H O
183 M2 XRST Reset for I/O Exp. L-H-L O
268 M3 RST_STATUS_IN Recognize AC IN/WatchDog, AC On:L WatchDog:H I
345 M4 BUFFER_CS Control for Chip Select Buffer of WatchDog, RST_STATUS_OUT:L O
89 N1 CHO_RXD_PW Dimmer Control,Normal: H Failure: L I
192 N2 BOX_SW PJ-Network Box Detection, Yes: H No: L I
287 N3 SCL_3.3V IIC Bus Control SCL,Active:L I/O
344 N4 SDA_3.3V IIC Bus Control SDA,Active:L I/O
413 N5 IRM_RST Reset for Gamma, S&H, Level Shift O
474 N6 WAKEUP I/O Exp. Wakeup O
329 AC9 A22 Address 22 O
249 AD10 A23 Address 23 O
160 AE12 A20 Address 20 O
65 AF12 A21 Address 21 O
To Next Page
