29
Computer Input
Press the MENU button to display the On-Screen
Menu. Press the Point 7 8 buttons to move the red
frame pointer to the PC Adjust Menu icon.
1
2
Press the Point ed buttons to move the red frame
pointer to the item that you want to adjust and then
press the SELECT button to display the adjustment
dialog box. Press the Point 7 8 buttons to adjust the
value.
Move the red frame
pointer to an item and
press the SELECT button.
PC Adjust Menu
PC Adjust Menu icon
Press the SELECT button
at this item to adjust other
items.
Press the Point
7 8buttons
to adjust the value.
Status (Stored / Free) of the
selected Mode.
Selected Mode
Press the SELECT button at
the Current mode item to
show the information of the
connected computer.
Manual PC Adjustment
Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector.
Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The
projector has five independent memory areas to memorize those parameters manually adjusted. It allows you
to recall the setting for a specific computer.
Use the Point 7 8 buttons to adjust the value, eliminating a
flicker from the image displayed (from 0 to 31).
Fine sync
Use the Point 7 8 buttons to adjust the number of total
dots in one horizontal period to match your PC image.
Total dots
Use the Point 7 8 buttons to adjust the horizontal picture
position.
Horizontal
Use the Point 7 8 buttons to adjust the vertical picture
position.
Vertical
Press the SELECT button to show H-sync freq. and V-sync
freq. of the connected computer.
Current mode
Use the Point 7 8 buttons to adjust the clamp level. When
the image has dark bars, try this adjustment.
Clamp
To Next Page
